6x6 Middle Hanger Bracket for Hanging a Hammock or Swing
Usage
Middle hanger brackets can be used to either a) hold a hammock in place between two of the pergola posts, or b) hang a swing from one of the pergola's beams. Simply secure the 6x6 hanger brackets to the posts or beam (using the stainless steel screws included) and then use the hole in the middle tabs to attach the hammock or swing.
6x6 Pergola Bracket Features
- Made with premium quality steel
- 12-gauge steel (~2.6mm thick)
- Made for dressed lumber commonly called 6x6s (actual dimensions are 5.5” x 5.5”)
- Laser-cut, bent and welded
- Advanced weather coating technology to withstand extreme weather conditions
- Pre-drilled holes for securing wood and accessories to bracket
- Includes stainless steel screws (1.5-inch #10 self-tapping wood screws with pan/round head painted black) for securing wood into bracket
- Reduces your pergola build time by as much as 75%
- Backed by a 5-year warranty
- Shipped directly to your doorstep from Boise, Idaho
Dimensions & Specifications
- Channel (arm) width: 5.8 inches (148 mm)
- Channel (arm) depth: 5.8 inches (148 mm)
- Channel (arm) height: 5.8 inches (148 mm)
- Middle tab dimensions: 5.8 inches (148mm) tall x 1.75 inches (45 mm) wide
- Inner dimensions of arm: 5.6 x 5.6 inches (143 x 143 mm) - made for 6x6 wood posts (which measure 5.5 x 5.5 inches)
- Holes on arm: 4 holes on 2 sides (additional holes can be drilled) - 0.25-inch holes ideal for #10 size screws (included)
- Weight: 4.0 pounds
- Not included: wood post, hammock/swing or parts
Specifications
- Bracket Specs: Channel (arm) width: 5.8 inches (148 mm) Channel (arm) depth: 5.8 inches (148 mm) Channel (arm) height: 5.8 inches (148 mm) Middle tab dimensions: 5.8 inches (148mm) tall x 1.75 inches (45 mm) wide Inner dimensions of arm: 5.6 x 5.6 inches (143 x 143 mm) - made for 6x6 wood posts (which measure 5.5 x 5.5 inches) Holes on arm: 4 holes on 2 sides (additional holes can be drilled) - 0.25-inch holes ideal for #10 size screws (included) Weight: 4.0 pounds Not included: wood post, hammock/swing or parts
- Brkt Dimensions: 5.8 x 5.8 x 5.8
- Brkt Dimensions Text: bracket is 5.8" wide x 5.8" deep x 5.8" tall (not including side tabs)
- Tabs on 1 Side: 1.75" tabs extend from the middle of one side (with 0.87" hole)
- High Capacity: holds up to 500 lbs. when used as a set of two brackets
- Screws Included: includes 1.5-inch screws (w/ black heads) for securing wood into bracket
- More Info About Kit: Middle hanger brackets can be used to either a) hold a hammock in place between two of the pergola posts, or b) hang a swing from one of the pergola's beams. Simply secure the 6x6 hanger brackets to the posts or beam (using the stainless steel screws included) and then use the hole in the middle tabs to attach the hammock or swing.
- Pre Key Info Brackets: used to hang a hammock between 2 posts
- Specs Text: 5.8" x 5.8" x 5.8" with 1.75" tab
- Features Text: 1.75" long tab on one side for attaching hammock
- Usage Text: used to hang a hammock between 2 posts
